RG-162 series EV reducer
RG162 series reducer meets the needs of mini electric cars with its superior quality and performance. The structure is compact and simple,the main reducer and differential device form a whole.The shell is made of high-quality ADC12 Aluminum Alloy with fine appearance and light weight.
Category:
Description
RG162 series reducer meets the needs of mini electric cars with its superior quality and performance. The structure is compact and simple,the main reducer and differential device form a whole.The shell is made of high-quality ADC12 Aluminum Alloy with fine appearance and light weight.The torque is suitable for medium and low-grade electric cars. The gears adopts constant mesh helical gear transmission. The gear design applies the optimization design of large coincidence degree to ensure the requirements of stable gear transmission, low noise, high transmission efficiency and long service life;
The high-speed shaft oil seal adopts high-quality FKM fluororubber sealing ring to ensure the sealing performance during high-speed operation;
| Model | RG162-00 | |||||||
| Structure | Two stage parallel shaft structure, including main reducer differential | |||||||
| Gear ratio | 6.43：1 | 7.97:1 | 10.01:1 | 11.73:1 | ||||
| Rated input torque | 30N.m | |||||||
| Max. input torque | 100N.m | |||||||
| Rated input speed | 5200r/min | |||||||
| Max. input speed | 7200r/min | |||||||
| Center distance | 162mm | |||||||
| Weight | 12KG | |||||||
| Dimension(L*W*H) | 375*240*153mm | |||||||
| Input spline data | Inside spline m1 z22 α20° JIS D2001 | |||||||
| Output spline data | Inside spline m1 z22 α20° JIS D2001 | |||||||
| Supporting scope | The product is suitable for micro McPherson suspension structure new energy vehicles with 5kw-10kw motor power. Suitable for various electric vehicles, |
|||||||
